Application |
Model |
Product |
Dimensions |
Radiant Flux |
Wavelength Range |
Driving Method |
Power |
|
Air Quality & Cleaning Appliances |
Air conditioning UVC sterilization module |
|
52mm×27mm×8mm |
15mW~30mW |
270nm~280nm |
Constant Voltage Drive,DC12V |
≤0.72W |
|
Home Appliance Surface Sterilization Module |
Space UVC sterilization module |
|
φ20mm×12mm |
8mW~10mW |
270nm~280nm |
Constant Voltage Drive,DC7V |
≤0.35W |
|
Tubular UVC Sterilization Module |
|
φ15mm×150mm |
60mW~80mW |
270nm~280nm |
Constant Voltage Drive,DC12V |
≤5.5W |
|
|
Intelligent toilet UVC sterilization module |
|
25mm×11mm×23mm |
12mW~20mW |
270nm~280nm |
Constant Voltage Drive,DC12V |
≤0.5W |
|
|
Intelligent toilet UVC sterilization module |
|
14mm×11mm×6mm |
/ |
8mW~10mW |
270nm~280nm |
Constant Voltage Drive,DC12V |
|
|
Transport robot UVC sterilization module |
|
138mm×38mm×23mm |
200mW~240mW |
270nm~280nm |
Constant Voltage Drive,DC12V |
≤3W |
|
|
Automotive UV LED Application |
Automotive refrigerator UVC sterilization module |
|
123mm×27mm×12mm |
≥50mW |
270nm~280nm |
Constant Voltage Drive,DC8V |
≤2.5W |
|
Air Quality & Cleaning Appliances |
Air conditioning UVC sterilization module |
|
87mm×29mm×32mm |
≥6mW |
270nm~280nm |
Constant Voltage Drive,DC12V |
≤0.5W |
|
Home Appliance Space Sterilization Module |
Washing Machine UVC Disinfection Module |
|
20.5mmx20.2mmx24.6mm |
6~8mW |
270nm~280nm |
Constant Voltage Drive,DC12V |
≤0.5W |
|
Washing Machine UVC Disinfection Module |
|
22mmx25.8mmx28mm |
≥2mW |
270nm~280nm |
Constant Voltage Drive,DC12V |
≤1W |
|
|
Washing Machine UVC Disinfection Module |
|
19.6mmx23mmx63mm |
≥16mW |
270nm~280nm |
Constant Voltage Drive,DC12V |
≤2.1W |
|
|
Washing Machine UVC Disinfection Module |
|
13.3mmx13.3xxx25mm |
≥6mW |
270nm~280nm |
Constant Voltage Drive,DC12V |
≤1W |
|
|
Home Appliance Lighting Module |
Washing Machine Lighting Module UVC022 |
|
24.8mmx24.8mmx23mm |
/ |
/ |
Constant Voltage Drive,DC9V |
≤0.5W |
Automotive Refrigerator UVC Module (UVC023)
UVLEDTEK Automotive Refrigerator UVC Module (UVC023) is applied to car refrigerators and vehicle health cabin systems. It eliminates bacteria and odors to keep food fresh and air clean in the car. It features vehicle-level reliability, low power consumption, efficient sterilization, compact structure and perfect adaptation to automotive environment.
UVLEDTEK air and surface UVC sterilization modules adopt 270–280nm germicidal LED chips with plug-and-play DC constant voltage drive. Custom optical and compact structural designs fit HVAC systems, smart toilets, washing machines, mobile disinfection robots and vehicle refrigerators, delivering reliable chemical-free surface & air disinfection with power ranging from 0.35W to 5.5W. As a professional Chinese manufacturer, we provide full OEM & ODM customization for global home appliance, automotive and sanitation equipment brands, with dedicated vehicle-grade UVC modules for car refrigerators available as extended solutions.
