Application |
Model |
Product |
Appearance Characteristics |
Operating Current (If) |
Operating Voltage (VF) |
Peak Wavelength (WLP) |
Optical Power (Po) |
Maintenance Rate |
|
Plant Growth, Medical Phototherapy, Optical Sensors, Bioanalysis/Detection. |
UVB LED Chip |
|
|
40mA |
5V~6.5V |
295nm~315nm |
6mW~15mW |
15000h@L70 |
|
|
|
100mA |
5V~6.5V |
295nm~315nm |
20mW~40mW |
15000h@L70 |
||
|
|
|
350mA |
5V~6.5V |
295nm~315nm |
40mW~100mW |
15000h@L70 |
UVB LED Chip (CFBS20M)
UVLEDTEK UVB LED chip (CFBS20M) is used in medical phototherapy, plant growth lighting, biological detection and analytical instruments. It provides precise and stable UVB light output for professional medical and horticultural applications. It features accurate wavelength control, uniform light intensity, long service life and good consistency, suitable for high-standard medical and detection equipment.
UVB LED Chip (CFBS20A)
UVLEDTEK UVB LED chip (CFBS20A) is applied to phototherapy equipment, horticulture lighting systems and UV sensing modules. It delivers stable UVB output to support effective phototherapy and plant lighting. It features reliable flip-chip design, good thermal stability, uniform luminescence and compatibility with standard assembly processes, ensuring high performance and long service life.
UVB LED Chip (CFBS45A)
UVLEDTEK UVB LED chip (CFBS45A) is designed for high-power phototherapy systems, industrial UV detection equipment and large-scale plant factory lighting. It provides high-power UVB output for large-area and high-intensity applications. It features strong optical output, durable structure, stable long-term performance and high reliability, meeting the requirements of professional medical and industrial scenarios.
UVLEDTEK UVB flip-chip LED chips emit stable 295–315nm UVB light with robust AuSn electrode design and 15,000-hour L70 lifespan. Three power grades (6–100mW) with matched CFBS20M/CFBS20A/CFBS45A models cover portable dermatology phototherapy, horticulture lighting and biological detection equipment. All chips operate at 5–6.5V with consistent uniform luminescence and good thermal stability, supporting mass OEM supply as a professional Chinese UVB chip manufacturer.
