Product Catalog
Please select product category
MAU002A Surface sterilization module
Operating Temperature
-40〜85 °C
humidity
0〜95 %RH
Protection level
IP67
UVC Rated voltage of LED package
DC 8 V
UVC Rated current of lamp bead
≤220 mA
Rated voltage of white light bulb
DC 12 V
MAU001A Surface sterilization module
rated voltage
DC 23±2 V
rated current
≥90 mA
rated power
＜2. 1 W
voltage-resistant insulation
' 10 MΩ
peak wavelength
270~280 nm
optical power
25-30 mW
MSS001A Surface sterilization module
Drive Type
constant current drive
UVC Rated current of lamp bead
100 mA
UVC Rated voltage of LED package
12 V
Rated current of white light bulb
10 mA
Rated voltage of white light bulb
3 V
MSS002A Surface sterilization module
Drive Type
constant voltage driving
rated voltage
12~16 V
rated power
≤3 W
UVC Lamp bead rated (total) current
≤240 mA
UVA Lamp bead rated (total) current
≤90 mA
UVC Number of LED package
4 pcs
popular
MIT001A Surface sterilization module
rated voltage
12 V
LED type
two-color, UVC+UVA
rated current
20 mA
rated power
0. 25 W
UVC Lamp pearl power
5~8 mW
UVC Peak wavelength of lamp bead
270~285 nm
MIT002A Surface sterilization module
Drive Type
constant voltage driving
rated voltage
12 V
rated current
20±5 mA
rated power
'0. 3 W
UVC Lamp pearl power
' 6 mW
UVC Peak wavelength of lamp bead
270~285 nm
popular
MIT003A Surface sterilization module
Drive Type
constant voltage driving
rated voltage
12 V
rated current
20±5 mA
rated power
0. 24 W
UVC Lamp pearl power
4~6 mW
UVC Peak wavelength of lamp bead
270~285 nm
MIT004A Surface sterilization module
Drive Type
constant voltage driving
rated voltage
12 V
rated current
35±5 mA
rated power
0. 4 W
UVC Lamp pearl power
5~8 mW
UVC Peak wavelength of lamp bead
270-285 nm
MDW002A Surface sterilization module
rated voltage
12 V
optical power
≥6 mW
peak wavelength
270~285 nm
Irradiation angle
120 °
Forward voltage drop
5. 1~6. 9 V
Electrostatic withstand voltage HBM
2 kV
MDW001A Surface sterilization module
Drive Type
constant voltage driving
rated voltage
12 V
rated current
50 mA
rated power
≤0. 7 W
optical power
6-8 mW
peak wavelength
270~285 nm
MWM002A Surface sterilization module
Drive Type
constant voltage driving
rated power
'1 W
optical power
≥2 mW
peak wavelength
270~285 nm
beam angle
120 °
Forward voltage drop
5~8 V
MWM003A Surface sterilization module
rated voltage
12 V
rated (total) current
≤175 mA
rated power
≤2. 1 W
Light power
≥16 mW
peak wavelength
270-280 nm
radiant angle
120 °
MWM004A Surface sterilization module
Drive Type
constant voltage driving
rated voltage
12 V
rated (total) current
≤80 mA
rated power
≤1 W
optical power
＞6 mW
peak wavelength
265~285 nm
MWM005A Surface sterilization module
Drive Type
constant voltage driving
rated voltage
9 V
rated current
≤50 mA
rated power
≤0. 5 W
Electrostatic withstand voltage HBM
2 kV
MWM001A Surface sterilization module
rated voltage
12 V
rated current
'50 mA
rated power
≤0. 5 W
optical power
6~8 mW
peak wavelength
275~285 nm
radiant angle
≥120 °
