new
MAC005A Air purification module
Operating Temperature
-10~45 °C
humidity
5~80 %RH
rated voltage
3~5 V
rated current
75~105 mA
rated power
0. 247~0. 346 W
optical power
6~8 mW
MAC004A Air purification module
rated voltage
12 V
rated (total) current
320 mA±6 %
optical power
≥25 mW
peak wavelength
270~280 nm
Light output angle
30 °
MAC003A Air purification module
rated voltage
12 V
rated power
≤1. 4 W
optical power
8~14 mW
peak wavelength
270~280 nm
radiant angle
30 °
Forward voltage drop
≤6 V
MAC002A Air purification module
rated current
55~65 mA
optical power
4~10 mW
peak wavelength
270~285 nm
Electrostatic withstand voltage HBM
2 kV
MAC001A Air purification module
rated voltage
12 V
rated current
≤120 mA
rated power
≤1. 5 W
optical power
≥8 mW
peak wavelength
260~285 nm
Light output angle
120 °
