UVC LED LED package

Product Catalog

Please select product category

LP2MQBB

LP2MQBB UVC LED LED package

optical power
15~30 mW
drive current
80 mA
wavelength
260~280 nm
Light output angle
120°
Working Voltage
5~7 V
LP2AQHB
recommend

LP2AQHB UVC LED LED package

optical power
40~70 mW
drive current
200 mA
wavelength
260~280 nm
Light output angle
120°
Working Voltage
5~7 V
LP2AHAC

LP2AHAC UVC LED LED package

optical power
40~70 mW
drive current
200 mA
wavelength
260~280 nm
Light output angle
30°
Working Voltage
5~7 V
LP2AHAA

LP2AHAA UVC LED LED package

optical power
40~70 mW
drive current
200 mA
wavelength
260~280 nm
Light output angle
60°
Working Voltage
5~7 V
LM218QQA

LM218QQA UVC LED LED package

optical power
400~600 mW
drive current
600 mA
wavelength
260~280 nm
Light output angle
60°
Working Voltage
15~21 V
LM44QPB

LM44QPB UVC LED LED package

optical power
200~400 mW
drive current
700 mA
wavelength
260~280 nm
Light output angle
120°
Working Voltage
11~14 V
LM24QPB

LM24QPB UVC LED LED package

optical power
70~150 mW
drive current
200 mA
wavelength
260~280 nm
Light output angle
120°
Working Voltage
10~14 V
LM24QMC

LM24QMC UVC LED LED package

optical power
70~150 mW
drive current
200 mA
wavelength
260~280 nm
Light output angle
30°
Working Voltage
10~14 V
LM2HQMC

LM2HQMC UVC LED LED package

optical power
200~400 mW
drive current
700 mA
wavelength
260~280 nm
Light output angle
30°
Working Voltage
11~14 V
LM2HQMB

LM2HQMB UVC LED LED package

optical power
200~400 mW
drive current
700 mA
wavelength
260~280 nm
Light output angle
120°
Working Voltage
11~14 V
LM1HQPB

LM1HQPB UVC LED LED package

optical power
150~350 mW
drive current
400 mA
wavelength
260~280 nm
Light output angle
120°
Working Voltage
10~14 V
LM1HQMB

LM1HQMB UVC LED LED package

optical power
100~200 mW
drive current
200 mA
wavelength
260~280 nm
Light output angle
120°
Working Voltage
11~14 V
LD2MQNB

LD2MQNB UVC LED LED package

optical power
6~15 mW
drive current
40 mA
wavelength
260~280 nm
Light output angle
120°
Working Voltage
5~7 V
LD2MQIB

LD2MQIB UVC LED LED package

optical power
3~10 mW
drive current
40 mA
wavelength
260~280 nm
Light output angle
120°
Working Voltage
5~7 V
LD2MQIA
Not recommended for new designs

LD2MQIA UVC LED LED package

optical power
6~15 mW
drive current
40 mA
wavelength
260~280 nm
Light output angle
60°
Working Voltage
5~7 V
