Flowing water sterilization module

Please select product category

MIT006A

MIT006A

270~285nm deep UV waterproof UVC LED sterilization module, instant disinfection and sterilization, health protection; Pure physical disinfection and sterilization, no chemical residue, safe and reliable; Low energy consumption design, energy-saving and environmentally friendly

rated voltage 12V
Rated current 100mA
electric power 1. 2W
Optical power 40mW
peak wavelength 270-280nm
Forward voltage drop 5~7V
MIT007A

MIT007A

270-285nm deep ultraviolet waterproof and sterilization module, intelligent bathroom UVC LED solution; Compact structure, easy to integrate; Low power design, 24-hour hygiene and safety protection

Drive mode constant voltage driving
rated voltage 12V
Rated current 300mA
electric power 3. 6W
Optical power 45mW
peak wavelength 270-280nm
MWP002A

MWP002A

Efficient sterilization, instant water purification; Circulating water system pathogen control, safe and pollution-free, no chemical residue, safeguarding water safety

Drive mode constant voltage driving
INPUT VOLTAGE DC12V/DC12-24V
Input Current ≤230/ ≤300mA
rated power
Handling traffic ≤2L/min
Optical power ≥50mW
MWP001A

MWP001A

Efficient sterilization, instant water purification; Modular design facilitates system integration; Safe and pollution-free, with no chemical residues, ensuring water safety

INPUT VOLTAGE 12±0. 5
Input Current ≤200mA
rated power
Handling traffic ≤2L/min
Optical power ≥35mW
peak wavelength 260~280nm
MWP003A

MWP003A

Modular design, supporting 7x24x hours of continuous operation; No chemical additives, ensuring pure water quality and meeting drinking water safety standards; Energy saving and durable, low maintenance cost

Drive mode constant voltage driving
INPUT VOLTAGE DC12-24V
Input Current ≤600mA
rated power ≤8W
Handling traffic 3L~5L
Optical power ≥45mW
MWP004A

MWP004A

Focus on UVC LED flowing water sterilization technology, and provide 99.99% efficient sterilization deep UV disinfection and sterilization module; Realize instant disinfection and sterilization and safe water treatment without chemical addition

Optical power ≥50mW
peak wavelength 270~280nm
radiant angle 60°
Forward voltage drop 5. 1~6. 9V
HBM electrostatic withstand voltage 2kV
INPUT VOLTAGE DC12-24V
MWP005A

MWP005A

Focused on UVC LED flow water sterilization module, 99.99% efficient sterilization, instant purification, safe and free of secondary pollution

INPUT VOLTAGE DC24±4V
Input Current ≥120mA
electric power <3. 0W
peak wavelength 270-280nm
Optical power 120mW
radiant angle 120°
MWP006A

MWP006A

Efficient sterilization, instant purification ● Safe and environmentally friendly, no secondary pollution ● Energy saving and durable, low maintenance cost

Drive mode constant voltage driving
INPUT VOLTAGE 3-5V
Input Current
rated power
internet traffic
sterilizing rate >99. 99%
MWP007A

MWP007A

Efficient sterilization, instant purification ● Safe and environmentally friendly, no chemical residue ● Ensuring water safety

Drive mode Constant current drive
INPUT VOLTAGE 11~13V
Input Current 200mA
Input power 2. 2-2. 6W
peak wavelength 270~280nm
radiant angle 120°
MWM005A

MWM005A

Sterilization rate ≥ 99.9%, professional technology, providing effective and reliable washing machine purification solutions

Drive mode constant voltage driving
rated voltage 9V
Rated current ≤50mA
rated power ≤0. 5W
Electrostatic Withstand Voltage (HBM) 2kV
LS003B

LS003B

Product size 124*23*18 mm
internet traffic 2 L/min
Drive mode constant voltage
Supply Voltage DC 12 V
Optical power ≥ 100 mW
sterilizing rate ≥ 99. 999%
AqueGuard-A

AqueGuard-A

Direct drinking water LED ultraviolet sterilizer

internet traffic 3 T/h
Number of light sources 1
A (mm) 400
B (mm) 380
C (mm) 158
D (mm) 90
