UVC LED LED package

Product Catalog

Please select product category

LD2MQBB
popular

LD2MQBB UVC LED LED package

optical power
6~15 mW
drive current
40 mA
wavelength
260~280 nm
Light output angle
120°
Working Voltage
5~7 V
LD2MHAC

LD2MHAC UVC LED LED package

optical power
6~15 mW
drive current
40 mA
wavelength
260~280 nm
Light output angle
30°
Working Voltage
5~7 V
LD2MHAA

LD2MHAA UVC LED LED package

optical power
6~15 mW
drive current
40 mA
wavelength
260~280 nm
Light output angle
60°
Working Voltage
5~7 V
LD2AQNB

LD2AQNB UVC LED LED package

optical power
15~50 mW
drive current
100 mA
wavelength
260~280 nm
Light output angle
120°
Working Voltage
5~7 V
LD2AQBB

LD2AQBB UVC LED LED package

optical power
15~50 mW
drive current
100 mA
wavelength
260~280 nm
Light output angle
120°
Working Voltage
5~7 V
LS4AQHB
recommend

LS4AQHB UVC LED LED package

optical power
50~175 mW
drive current
350 mA
wavelength
260~280 nm
Light output angle
120°
Working Voltage
5~7 V
LD2AHAA

LD2AHAA UVC LED LED package

wavelength
260~280 nm
optical power
15~50 mW
Working Voltage
5~7 V
Light output angle
60°
Package Size
3535
Lamp bead height
3. 05 mm
LS2MQBB

LS2MQBB UVC LED LED package

wavelength
260~280 nm
optical power
6~15mW
drive current
40 mA
Working Voltage
5~7 V
Light output angle
120°
Substrate material
aluminum nitride
LD2MQFB
new

LD2MQFB UVC LED LED package

optical power
4-10 mW
drive current
40 mA
wavelength
260~280 nm
Light output angle
120°
Package Size
3535
Substrate material
polymer materials
